03、platform_device 如何与 platform_driver 配对

从设备树转换得来的 platform_device 会被注册进内核里，以后当我们每 注册一个 platform_driver 时，它们就会调用 platform_match 确定能否配对，如果能配对成功 就调用 platform_driver 的 probe 函数。

static int platform_match(struct device *dev, struct device_driver *drv)
{
        struct platform_device *pdev = to_platform_device(dev);
        struct platform_driver *pdrv = to_platform_driver(drv);

        /* When driver_override is set, only bind to the matching driver */
        if (pdev->driver_override)
                return !strcmp(pdev->driver_override, drv->name);

        /* Attempt an OF style match first */
        if (of_driver_match_device(dev, drv))
                return 1;

        /* Then try ACPI style match */
        if (acpi_driver_match_device(dev, drv))
                return 1;

        /* Then try to match against the id table */
        if (pdrv->id_table)
                return platform_match_id(pdrv->id_table, pdev) != NULL;

        /* fall-back to driver name match */
        return (strcmp(pdev->name, drv->name) == 0);
}

一、强制绑定机制

---

如果设备设置了 driver_override，则只与名称完全匹配的驱动绑定

这是一种强制绑定机制，优先级最高

        /* When driver_override is set, only bind to the matching driver */
        if (pdev->driver_override)
                return !strcmp(pdev->driver_override, drv->name);

二、设备树匹配

尝试使用设备树(Open Firmware)风格的匹配

检查设备树节点与驱动的兼容性字符串是否匹配

        /* Attempt an OF style match first */
        if (of_driver_match_device(dev, drv))
                return 1;

of_driver_match_device 函数实现如下：

/**
 * of_driver_match_device - Tell if a driver's of_match_table matches a device.
 * @drv: the device_driver structure to test
 * @dev: the device structure to match against
 */
static inline int of_driver_match_device(struct device *dev,
                                         const struct device_driver *drv)
{
        return of_match_device(drv->of_match_table, dev) != NULL;
}

of_match_device 是 Linux 内核中用于检查设备是否与设备树匹配表(of_device_id)匹配的关键函数。

const struct of_device_id *of_match_device(const struct of_device_id *matches,
                                           const struct device *dev)
{
        if ((!matches) || (!dev->of_node))
                return NULL;
        return of_match_node(matches, dev->of_node);
}
EXPORT_SYMBOL(of_match_device);

/**
 * of_match_node - Tell if a device_node has a matching of_match structure
 *      @matches:       array of of device match structures to search in
 *      @node:          the of device structure to match against
 *
 *      Low level utility function used by device matching.
 */
const struct of_device_id *of_match_node(const struct of_device_id *matches,
                                         const struct device_node *node)
{
        const struct of_device_id *match;
        unsigned long flags;

        raw_spin_lock_irqsave(&devtree_lock, flags);
        match = __of_match_node(matches, node);
        raw_spin_unlock_irqrestore(&devtree_lock, flags);
        return match;
}
EXPORT_SYMBOL(of_match_node);

__of_match_node  中 最后会调用__of_device_is_compatible

static int __of_device_is_compatible(const struct device_node *device,
                                     const char *compat, const char *type, const char *name)
{
        struct property *prop;
        const char *cp;
        int index = 0, score = 0;

        /* Compatible match has highest priority */
        if (compat && compat[0]) {
                prop = __of_find_property(device, "compatible", NULL);
                for (cp = of_prop_next_string(prop, NULL); cp;
                     cp = of_prop_next_string(prop, cp), index++) {
                        if (of_compat_cmp(cp, compat, strlen(compat)) == 0) {
                                score = INT_MAX/2 - (index << 2);
                                break;
                        }
                }
                if (!score)
                        return 0;
        }

        /* Matching type is better than matching name */
        if (type && type[0]) {
                if (!device->type || of_node_cmp(type, device->type))
                        return 0;
                score += 2;
        }

        /* Matching name is a bit better than not */
        if (name && name[0]) {
                if (!device->name || of_node_cmp(name, device->name))
                        return 0;
                score++;
        }

        return score;
}

三、id_table ID表匹配

检查驱动是否提供了 ID 表(id_table)

如果有，则尝试在 ID 表中查找匹配的设备 ID

        /* Then try to match against the id table */
        if (pdrv->id_table)
                return platform_match_id(pdrv->id_table, pdev) != NULL;

重点platform_match_id分析

static const struct platform_device_id *platform_match_id(
                        const struct platform_device_id *id,
                        struct platform_device *pdev)
{
        while (id->name[0]) {
                if (strcmp(pdev->name, id->name) == 0) {
                        pdev->id_entry = id;
                        return id;
                }
                id++;
        }
        return NULL;
}

四、匹配名字

---

最后回退到简单的名称匹配

比较设备名称和驱动名称是否完全相同

        /* fall-back to driver name match */
        return (strcmp(pdev->name, drv->name) == 0);
